Aprilog QFP - TQFP Pin Monitor Adapters

QFP & TQFP Site Monitor Adapters

This adapter provides easy access connection points for test instrumentation, signal injection, and temporary external circuit connection.
It consists of two parts, a bed of nails SMT base that has the same footprint as the IC surface mount pads and top module. The top module has a QFP or TQFP ZIF socket for the test component and mating receptacle for the SMT base

Adapters on these pages are listed in ascending order by the number of pins.

Part Number Description Price Shopping Cart

M32QFS31-QF-ZO-SD 32 pin QFP Pin Monitor Adapter

QFP Package Type
32 Pins
9.0 mm Tip to Tip
0.8 mm Pitch
Open Top ZIF Socket
$256.00

M44QFS31A-QF-ZL-SD 44 pin QFP Pin Monitor Adapter

QFP Package Type
44 Pins
12.0 mm Tip to Tip
0.8 mm Pitch
Clamshell hinged lid ZIF Socket
$325.00

M44QFS31B-QF-ZO-SD 44 pin QFP Pin Monitor Adapter

QFP Package Type
44 Pins
13.2 mm Tip to Tip
0.8 mm Pitch
Open top ZIF Socket
$325.00

M44QFS31C-QF-ZL-SD 44 pin QFP Pin Monitor Adapter

QFP Package Type
44 Pins
12.6 mm Tip to Tip
0.8 mm Pitch
Clamshell hinged lid ZIF Socket
$325.00

M48QFS20-QF-ZO-SD2 48 pin QFP Pin Monitor Adapter

QFP Package Type
48 Pins
0.5 mm Pitch
Open top ZIF Socket
$395.00

M64QFR39B-QF-ZL-SD 64 pin QFP Pin Monitor Adapter

QFP Package Type
64 Pins
17.9 x 23.9mm Tip to Tip
1. mm Pitch
Clamshell hinged lid ZIF Socket
$350.00

M64QFS20-QF-ZL-SD 64 pin TQFP Pin Monitor Adapter

TQFP Package Type
64 Pins
12.0 mm Tip to Tip
.5 mm Pitch
Clamshell hinged lid ZIF Socket
$395.00

M64QFS31B-QF-ZL-SD 64 pin QFP Pin Monitor Adapter

QFP Package Type
64 Pins
17.9 mm Tip to Tip
.8 mm Pitch
Clamshell hinged lid ZIF Socket
$350.00

M80QFR31A-QF-ZL-SD 80 pin QFP Pin Monitor Adapter

QFP Package Type
80 Pins
17.2 x 23.2mm Tip to Tip
.8 mm Pitch
Clamshell hinged lid ZIF Socket
$395.00

M80QFR31B-QF-ZL-SD 80 pin QFP Pin Monitor Adapter

QFP Package Type
80 Pins
17.9 x 23.9mm Tip to Tip
.8 mm Pitch
Clamshell hinged lid ZIF Socket
$395.00

M80QFR31C-QF-ZL-SD 80 pin QFP Pin Monitor Adapter

QFP Package Type
80 Pins
17.6 x 23.6mmTip to Tip
.8 mm Pitch
Clamshell hinged lid ZIF Socket
$395.00

M80QFS20-QF-ZL-SD 80 pin QFP Pin Monitor Adapter

TQFP Package Type
80 Pins
14mmTip to Tip
.5 mm Pitch
Clamshell hinged lid ZIF Socket
$435.00

M80QFS26A-QF-ZL-SD 80 pin QFP Pin Monitor Adapter

QFP Package Type
80 Pins
17mmTip to Tip
.65 mm Pitch
Clamshell hinged lid ZIF Socket
$385.00

M80QFS26D-QF-ZL-SD 80 pin QFP Pin Monitor Adapter

QFP Package Type
80 Pins
16mmTip to Tip
.65 mm Pitch
Clamshell hinged lid ZIF Socket
$385.00

M100QFR26C-QF-ZL-SD 100 pin QFP Pin Monitor Adapter

QFP Package Type
100 Pins
17.6 x 23.6mm Tip to Tip
.65 mm Pitch
Clamshell hinged lid ZIF Socket
$424.00

M100QFS20-QF-ZO-SD 100 pin QFP Pin Monitor Adapter

TQFP Package Type
100 Pins
16mm Tip to Tip
.5 mm Pitch
Open Top ZIF Socket
$488.00

M160QFS26A-QF-ZL-SD 160 pin QFP Pin Monitor Adapter

QFP Package Type
160 Pins
31.2mm Tip to Tip
.65 mm Pitch
Clamshell hinged lid ZIF Socket
$472.00
