Nohau 80C51 & 80C31 In-Circuit Emulators Pods

The pods replace the CPU on the hardware under test. Many pods have PLCC or DIP socket pins. Others have a pin grid array that plug into adapters for target hardware sockets or surface mount emulation adapters.
In-circuit Pods for 80C51 and 80C31 Series Processors To 80C51 emulator shopping menu Adapters To Component Site Shopping home page Links - Site and product

Part Number	80C31/80C51 Series emulator in-circuit pods - Required -	Price	Shopping Cart
POD-C054	80C054 12 MHz, 40 pin DIP emulator in-circuit pod	$195.00
POD-CL410	80CL410 12 MHz, 40 pin DIP emulator in-circuit pod	$95.00
POD-CL580-16	80CL580 16 MHz, 40 pin DIP emulator in-circuit pod	$95.00
POD-CL782	Intel 85CL782, 40 pin DIP emulator in-circuit pod	$95.00
POD-C152-DIP-16	80C152 16 MHz, 40 pin DIP emulator in-circuit pod	$495.00
POD-C152-PGA-16	80C152 16 MHz, emulator in-circuit pod, PGA Connection requires a target DIP or PLCC to pod adapter.	$495.00
POD-C154HF-42	80C154 42 MHz emulator in-circuit pod	$495.00
POD-C31	8031 12-MHz emulator in-circuit pod	$95.00
POD-C31-16	80C31 16-MHz emulator in-circuit pod	$395.00
POD-C31-33	80C31 33-MHz emulator in-circuit pod	$795.00
POD-C31-S	80C31 12MHz, Single chip mode emulator in-circuit pod.	$395.00
POD-C31-S-16	80C31 16MHz, Single chip mode emulator in-circuit pod.	$445.00
POD-C31-S-24	80C31 24MHz, Single chip mode emulator in-circuit pod.	$495.00
POD-C32	8032 12-MHz emulator in-circuit pod	$95.00
POD-C32-16	80C32 16-MHz emulator in-circuit pod	$445.00
POD-C32-BSW-12	80C32 Bank Switching, 12-MHz emulator in-circuit pod	$195.00
POD-C32-BSW-16	80C32 Bank Switching, 16-MHz emulator in-circuit pod	$495.00
POD-C32-30	80C32 30-MHz in-circuit pod	$745.00
POD-C32HF-42	42-MHz 80C32 high frequency pod. Requires EA emulator card for 42 MHz. This pod is capable of bank switching up to the emulator frequency with EA256/768-BSW-50 and E128/256-BSW emulators.	$995.00
POD-C320-25	For Dallas DS80C320 DIP In-circuit pod 25 MHz max.	$795.00
POD-C320-33	For Dallas DS80C320 DIP In-circuit pod 33 MHz max.	$995.00
POD-C321	For Intel 80C321 DIP In-circuit pod 16 MHz max.	$345.00
POD-44	80C44 12 MHz emulator in-circuit pod, 40-Pin DIP connection	$345.00
POD-C451-DIP-16	80C451 16 MHz emulator in-circuit pod, 40 pin DIP connection	$195.00
POD-C451-PGA	80C451 12 MHz emulator in-circuit pod, pin grid array connection	$95.00
POD-C451-PGA-16	80C451 16 MHz emulator in-circuit pod, pin grid array connection	$395.00
POD-C452	80C452 12MHz emulator in-circuit pod	$195.00
POD-C505C	Siemens SAFC505CL,16 MHz max clock In-circuit emulator pod	$495.00
POD-C51	80C51 12 MHz emulator in-circuit pod	$195.00
POD-C51-16	80C51 16 MHz emulator in-circuit pod	$395.00
POD-C51B	80C51 12 MHz emulator in-circuit pod	$295.00
POD-C51B-16	80C51 16 MHz emulator in-circuit pod	$395.00
POD-C51B-24	80C51 24 MHz emulator in-circuit pod	$495.00
POD-51EH-C504-40	40-MHz enhanced hooks mode pod for the Infineon C504. Consists of an add-on processor module for C504 (PM51-EH-SAB-C504) and an enhanced hooks port replacement unit (EMUL51-PC/PRU-EH). Interchangeable add-on processor modules for other derivatives can be used with the enhanced hooks port replacement unit. Requires 50-MHz trace and emulator boards. This pod is designed to plug into a 44-pin PGA to 44-pin QFP solder-down adapter, such as the EDI/44PG/QFS31-SD. This requires the SAMTEC/MPAT-044-A-G-80; a 44-pin male-to-male PGA adapter for use with the POD-C51EH series. Supports both external and internal modes.	$995.00
POD-51EH-C505C-20	20-MHz enhanced hooks mode pod for the Infineon C505C. Requires 50-MHz trace and emulator boards for 20-MHz operation. (Note: The 20 MHz for this derivative corresponds to 40 MHz for a regular 8031.) Consists of an add-on processor module for C505C (PM51-EH-SAB-C505C) and enhanced hooks port replacement unit (EMUL51-PC/PRU-EH). Interchangeable add-on processor modules for other derivatives can be used with the enhanced hooks port replacement unit. This pod is designed to plug into a 44-pin PGA to 44-pin QFP solder-down adapter, such as the EDI/44PG/QFS31-SD. Supports both external and internal modes.	$995.00
POD-51EH-C505CA-20	Supports C505CA - 2R - LM. Infineon 20-MHz in-circuit emulator pod. Requires 50-MHz trace and emulator boards for 20-MHz operation. Consists of an add-on processor module for C505CA (PM51-EH-SAB-C505CA) and an enhanced hooks port replacement unit (EMUL51-PC/PRU-EH). Interchangeable add-on processor modules for other derivatives can be used with the enhanced hooks port replacement unit. This pod is designed to plug into a 44-pin PGA to 44-pin QFP solder-down adapter, such as the EDI/44PG/QFS31-SD Supports both external and internal modes.	$995.00
POD-51EH-C505L-20	20-MHz enhanced hooks mode pod for the Infineon C505L consists of an add-on processor module for C505L (PM51-EH-C505L) and an enhanced hooks port replacement unit (EMUL51-PC/PRU-EH). Interchangeable add-on processor modules for other derivatives can be used with the enhanced hooks port replacement unit. Requires 50-MHz trace and emulator boards for 20-MHz operation. Adapters for the P-MQFP package are available. (ES/180-5550-65) Supports both external and internal modes.	$995.00
POD-51EH-C508-10	10-MHz enhanced hooks mode pod for the Infineon C508 (Note: The 10 MHz for this derivative corresponds to 40 MHz for a regular 8031.) Consists of an add-on processor module for C508 (PM51-EH-C508) and the enhanced hooks port replacement unit (EMUL51-PC/PRU-EH). Interchangeable add-on processor modules for other derivatives can be used with the enhanced hooks port replacement unit. Requires 50-MHz trace and emulator boards. Adapters for the PMQFP see ES/180-5545-00. Supports both external and internal modes.	$995.00
POD-51EH-C513A0-16	16-MHz enhanced hooks mode pod for the Infineon 80C513AO consists of an add-on processor module for C513AO (PM51-EH-C513AO) and an enhanced hooks port replacement unit (EMUL51-PC/PRU-EH). Interchangeable add-on processor modules for other derivatives can be used with the enhanced hooks PRU. Requires 50-MHz trace and emulator boards For the P-MQFP package order adapter Part # EDI44PG44QFS31S2. For the PLCC44 package order adapter Part # EDI/1EP44PL-L. Supports both external and internal modes..	$995.00
POD-51EH-C515-10	10-MHz enhanced hooks mode pod for the Infineon C515. Consists of an add-on processor module for C515 (PM51-EH-SAB-C515) and an enhanced hooks port replacement unit (EMUL51-PC/PRU-EH). Interchangeable add-on processor modules for other derivatives can be used with the enhanced hooks port replacement unit. Requires 24-MHz trace and emulator boards. Adapters for the PMQFP package are available (see ES/180-5550-40 and ES/180-5550-45.) Supports both external and internal modes.	$795.00
POD-51EH-C515-24	24-MHz enhanced hooks mode pod for the Infineon C515. Consists of an add-on processor module for C515 (PM51-EH-SAB-C515) and an enhanced hooks port replacement unit (EMUL51-PC/PRU-EH). Interchangeable add-on processor modules for other derivatives can be used with the enhanced hooks port replacement unit. Requires 24-MHz trace and emulator boards. Adapters for the PMQFP package are available (see ES/180-5550-40 and ES/180-5550-45.) Supports both external and internal modes.	$995.00
POD-51EH-C517A-24	For the Infineon 80C517A, 80C517A4RM, 80C517A4RN, 80C517ALM, 80C517ALN up to 24-MHz clock. Other add-on PRU processor modules supporting other derivatives can be used with this pod.	$995.00
POD-51EH-C541U-12	12-MHz In circuit pod for AMD 80C541. Requires ES/180-3900-00 44 pin PLCC pod to target site adapter.	$995.00
POD-51EH-TSRD2-32	32-MHz pod for Atmel TS83C51Rx2 and TS87C51Rx2. This pod supports a 32-MHz x1 clock or a 16-MHz x2 clock	$995.00
POD-C51FA-16	80C51FA 16 MHz emulator in-circuit pod	$445.00
POD-C51-FX-16	8XC51FA/ FB/ FC, 8XC51/ 52/ 54/ 58, 8X51/ 52, 80C31/ 32, 8031/ 32. 16-MHz hooks-mode pod. 40-pin DIP. Uses Intel special emulation technology chip.	$1,095.00
POD-C51-FX-24	8XC51FA/ FB/ FC, 8XC51/ 52/ 54/ 58, 8X51/ 52, 80C31/ 32, 8031/ 32. 24-MHz hooks-mode pod. 40-pin DIP. Uses Intel special emulation technology chip.	$1,295.00
POD-C51GB-PGA	80C51GB emulator in-circuit pod	$49.00
POD-51HB-C52-33	33-MHz maximum clock in-circuit pod for the Philps NXP 8XC51/ 52 / 54 / 58, 8X51/ 52, 80C31/ 32, 8031/ 32. This pod terminates to a 44-pin PGA and requires an adatper to the target board MPu site.	$1,195.00
POD-51HB-C51RX-33	8XC51RA/ RB/ RC/ RD+ NXP Philips 33-MHz hooks-mode pod Requires the EMUL51-PC/EA256-BSW-50 emulator board and optional 16K, 50-MHz standard trace or at least a 33-MHz enhanced trace board. This pod terminates to a 44-pin PGA. For the 44-pin PLCC package order part # EDI/1EP44PL-L. For the QFP package order part # EDI/44PG/QFS31-SD. For a 40-pin DIP package order adapter EDI/44PG/40D-S-8051.	$1,195.00
POD-51HB-C66x	NXP Philips 80C66x 20-MHz emulator in-circuit pod for the 6-clock series 8xC660, 8xC662, 8xC664 and 8xC668. This pod requires 50-MHz trace and emulator boards. For the 44-pin PLCC package order adapter part # EMUL51-PC/ PGA44-PLCC44. For the QFP package order adapter part # EDI/44PG/QFS31-SD. This pod terminates to a 44-pin PGA.	$1,195.00
POD-51HB-C591-16	16-MHz hooks-mode pod for the 6-clock NXP Philips 80C591. This pod requires 50-MHz trace and emulator boards. For the 44-pin PLCC package order adapter part # EMUL51-PC/PGA44-PLCC44. For the QFP package order adapter part # EDI/44PG/QFS31-SD.	$1,195.00
POD-51HB-C66x-20	20-MHz hooks-mode pod for the 6-clock NXP Philips C66x. This pod For the 44-pin PLCC package order adapter part # EMUL51-PC/ PGA44-PLCC44. For the QFP package order adapter part # EDI/44PG/QFS31-SD. This pod terminates to a 44-pin PGA. If this pod is to be operated above 18 MHz, please contact ICE Technology for a special cable. Supports the 8xC660, 8xC662, 8xC664 and 8xC668.	$1,195.00
POD-C51MX-MC2	24 MHz pod for the 6-clock NXP Philips 80C51MX architecture	$1,395.00
EMUL51-PC/PRU-EH	Configurable in-circuit pod for use with add-on processor configuration modules.	$500.00
PM51-EH-C505C	Controller configuration module for EMUL51-PC/PRU-EH configurable in-circuit pod. Supports Infinion C505C-2R (16K mask-ROM version of the C505C), C505-2R (16K mask-ROM version of the C505) and C505-LM (ROM-less version of the C505) only.	$495.00
PM51-EH-C505CA	Controller configuration module for EMUL51-PC/PRU-EH configurable in-circuit pod. Supports Infinion C505CA-4E (32K OTP version of the C505CA), C505CA-L (ROM-less version of the C505CA), C505A-4E (32K OTP version of the C505A) and C505A-L (ROM-less version of the C505A) only.	$495.00
PM51-EH-C508C	Controller configuration module for EMUL51-PC/PRU-EH configurable in-circuit pod. Supports Infinion C508-4EM (MQFP 32K OTP version of the C508) and C508-4RM (MQFP 32K mask-ROM version of the C508) only.	$495.00
\PM51-EH-SAB-C515A	Controller configuration module for for EMUL51-PC/PRU-EH configurable in-circuit pod. Supports InfinionC515A-4R (32K Mask-ROM version) and C515A-L (ROM-less version)	$495.00
PM-C541U	Controller configuration module for for EMUL51-PC/PRU-EH configurable in-circuit pod. Supports Siemens SAB-C54U	$495.00
POD-51-uPSD3000	40-MHz uPSD3200 architecture in circuit pod. The pod contains a bondout chip, a socketed PSD device that can be changed to your target device and a JTAG programming connector. The pod terminates to four male headers. The headers mate with the ST Microelectronics DK3000 evaluation board, or the 52 or 80-pin target adapter sets.	$995.00
POD-51T-89C51ED2	Atmel TS89C51ED2 in-circuit pod for 44-Pin PLCC socket. This pod supports a 32-MHz x1 clock or a 16-MHz x2 clock.	$995.00
POD-51T-89C51ED2-68	Atmel TS89C51ED2 in-circuit pod for 68-Pin PLCC socket. This pod supports a 32-MHz x1 clock or a 16-MHz x2 clock.	$995.00
POD-51T-8xC51RC2-44	Atmel TS83C51Rx2 and TS87C51Rx2 in-circuit pod for 44-Pin PLCC socket. This pod supports a 32-MHz x1 clock or a 16-MHz x2 clock.	$995.00
POD-51T-89C51RD2-68	Atmel TS83C51Rx2, TS87C51Rx2, AT89C1051, & AT89C2051 in-circuit pod. This pod supports a 32-MHz x1 clock or a 16-MHz x2 clock. For 68-Pin PLCC socket.	$995.00
POD-51T-89V664	NXP 89V664 in-circuit pod. This pod supports a 32-MHz x1 clock or a 16-MHz x2 clock.	$995.00
POD-51TS-89C51CC01	32-MHz pod for Atmel T89C51CC01. This pod supports a 32-MHz x1 clock or a 16-MHz x2 clock. Pod PGA pins require EDI/44PG/QFS31-SD SMT emulator to PCB pads adapter.	$995.00
POD-51TS-89C51CC03	32-MHz pod for Atmel T89C51CC03. This pod supports a 32-MHz x1 clock or a 16-MHz x2 clock. Pod PGA pins require EDI/44PG/QFS31-SD SMT emulator to PCB pads adapter.	$995.00
POD-C51RX	8XC51RA/ RB/ RC in-circuit emulator pod, 12 MHz max	$495.00
POD-C51RX-16	8XC51RA/ RB/ RC in-circuit emulator pod, 16 MHz max	$595.00
POD-C51RX-P-33	8XC51RA/ RB/ RC in-circuit emulator pod, 33 MHz max	$1,195.00
POD-51SL-16	80C51SL 16 MHz Low voltage keyboard processor pod	$395.00
POD-C515A-12	80C515 12-MHz (ROM-less) pod. For enhanced 80C515A. 80C515A chip must be supplied by user. Expanded on-chip RAM is not supported. Use a 20-MHz or faster emulator for 12-MHz operation. 68-pin PGA from pod. Use optional EMUL51-PC/PGA68-PLCC68 adapter for PLCC target. Port 2 is upper address bus only. Port 0 is address/data bus. P3.6 is WRITE, P3.7 is READ.	$145.00
POD-C515A-18	80C515A 18-MHz (ROM-less) pod. For enhanced 80C515A. 80C515A chip must be supplied by user. Expanded on-chip RAM is not supported. Use a 20-MHz or faster emulator for 18-MHz operation. 68-pin PGA from pod. Use optional EMUL51-PC/PGA68-PLCC68 adapter for PLCC target. Port 2 is upper address bus only. Port 0 is address/data bus. P3.6 is WRITE, P3.7 is READ.	$195.00
POD-517B	80C517B 12 MHz emulator in-circuit pod	$195.00
POD-517B-PGA	80C517B 12 MHz emulator in-circuit pod with PGA adapter interface	$195.00
POD-C252/C51FA-BSW-16	80C252 & 80C51FA 16 MHz Bank Switching emulator in-circuit pod	$195.00
POD-C52	8XC51/ 52 / 54 / 58, 8X51/ 52, 80C31/ 32, 8031/ 32, Single chip mode, 12-MHz pod for 40pin DIP.	$695.00
POD-C52-20	8XC51/ 52 / 54 / 58, 8X51/ 52, 80C31/ 32, 8031/ 32, Single chip mode, 20-MHz pod for 40pin DIP.	$895.00
POD-51HB-C52-24	24-MHz maximum, hooks-mode pod for 8XC51/ 52 / 54 / 58, 8X51/ 52, 80C31/ 32, 8031/ 32. Requires an EMUL51-PC/EA256-BSW-50 and an optional 16-kiloframe, 50-MHz standard trace or at least a 33-MHz advanced trace board or a 50-MHz enhanced trace board. This pod terminates to a 44-pin PGA.	$995.00
POD-51HB-C52-33	33-MHz hooks-mode pod for 8XC51/ 52 / 54 / 58, 8X51/ 52, 80C31/ 32, 8031/ 32. Requires an EMUL51-PC/EA256-BSW-50 and an optional 16-kiloframe, 50-MHz standard trace or at least a 33-MHz advanced trace board or a 50-MHz enhanced trace board. This pod terminates to a 44-pin PGA.	$1,395.00
POD-C520-PGA-33	DS8XC520, DS8XC530 and DS80C320 33-MHz pod. Pod operates only with EA256-C530-BSW-33 or EA768-C530-BSW-33 emulator boards. 52-pin PGA connection from the pod. To plug into a 40-pin DIP 'C520 or 'C320-target socket, use optional EDI/52PG/40D-530/520-S adapter. To plug into a 44-pin PLCC 'C520 socket, use optional EDI/52PG/44PL-530/520. To plug into a 52-pin LCC 'C530 socket, use optional PGA52-PLCC52. Optional trace board must be EMUL51-C/TR16-50, EMUL51-PC/ETR64-50 or EMUL51-PC/ETR256-50.	$1,295.00
POD-C528-16	8XC528, 8XC524 16-MHz hooks-mode emulator in-circuit pod for 40-pin DIP.	$495.00
POD-C528-20	8XC528, 8XC524 20-MHz hooks-mode emulator in-circuit pod for 40-pin DIP.	$895.00
POD-C535-DIP-12	80C535 emulator in-circuit pod 12MHz max clock for DIP socket	$195.00
POD-C535-PGA-12	80C535 emulator in-circuit pod 12MHz max clock for PGA socket adapters.	$195.00
POD-C537	80C537 emulator in-circuit pod 16MHz	$195.00
POD-C542	80C542 emulator in-circuit pod 16MHz	$195.00
POD-C550-PGA	80C550 12 MHz PGA emulator in-circuit pod. Requires a PGA to target adapter.	$195.00
POD-C552-PGA-16	80C552 16 MHz emulator in-circuit pod. Port 2 is upper address bus only. Port 0 is address/data bus. P3.6 is WRITE, P3.7 is READ.	$195.00
POD-C552-PGA-24	80C552 24 MHz emulator in-circuit pod. Port 2 is upper address bus only. Port 0 is address/data bus. P3.6 is WRITE, P3.7 is READ.	$215.00
POD-C552-PGA-33	80C552 30 MHz emulator in-circuit pod. Port 2 is upper address bus only. Port 0 is address/data bus. P3.6 is WRITE, P3.7 is READ.	$295.00
POD-C554-PGA-33	33-MHz hooks mode pod for the NXP Philips 8xC554, 2.7 V to 5.5 V (maximum 16 MHz at 5 V) Requires the EMUL51-PC/EA256-BSW-50 emulator board and optional 16K 50-MHz standard or enhanced trace or at least a 33-MHz advanced trace board. The EMUL51-PC/PGA68-PLCC68 adapter is required to mate to target.	$995.00
POD-C558-16	16-MHz hooks-mode pod for 8xC557, 83CE558, 89CE558, 8xCE559 and 8xCE560. Contact Nohau for availability. Use ET/EPP-080-QF08-LG adapter to solder to user target board. The pod contains a 16-MHz crystal. The emulator must be at least 16 MHz to run with an on-board pod crystal, but a 12-MHz emulator can be used with a 12-MHz or slower external crystal or oscillator.	$195.00
POD-C558-16-BSW	8xC557, 83CE558, 89CE558, 8xCE559 and 8xCE560 16 MHz bank switching emulator in-circuit pod Use ET/EPP-080-QF08-LG adapter to solder to your target board.	$295.00
POD-C576-16	80C576 16 MHz emulator in-circuit pod.	$195.00
POD-C591-16	NXP NXP Philips 8xC591, 16-MHz, 6-clock hooks-mode pod . This pod requires 50-MHz trace and emulator boards. For the 44-pin PLCC package order adapter part # EMUL51-PC/PGA44-PLCC44. For the QFP package order adapter part # EDI/44PG/QFS31-SD.	$1,195.00
POD-C592-PGA-16	80C592 16 MHz emulator in-circuit pod. Use EDI/68PG/80QFR31-SD-592 adapter.	$995.00
POD-C652-S	80C652,12 MHz emulator in-circuit pod, single chip mode.	$95.00
POD-C654-DIP	80C654,12 MHz emulator in-circuit pod, DIP I/O pins.	$95.00
POD-C751-16	80C751,16 MHz emulator in-circuit pod.	$95.00
POD-C752	80C752 12 MHz emulator in-circuit pod.	$95.00
POD-C752-16	80C752 16 MHz emulator in-circuit pod.	$295.00
POD-C754	80C754 emulator in-circuit pod.	$195.00
